Model: LFZX-900C
Introduction: It is fully automatic Carton Boxing Packing Machine. it could weight and fill 125g to 25kg product into the box, cartons automatically. It is suitable for all kinds of granular and solid materials, such as parts, accessories, hardware, fasteners, metal pipes, furniture fitting, plastic items, spare part, granule, nuts, screws, long nails, etc, and can be flexibly selected and configured according to the materials.
E-mail: sales@landpacking.com
Tel/Whtasapp: +86 17388602385
Application:
1. Fasteners: screw, bolt, nut, washer, rivets, nails etc.
2. Plastic/Rubber Parts: wall anchor, rubber o-rings, toys, lego building bricks, small plastic parts.
3. Hardware Parts: hardware components, hardware connectors, metal parts etc.
4. Furniture Accessories: furniture connectors, furniture fasteners, furniture fittings, furniture accessories, door handle, hinge etc.
5. Others: small hardware or plastic parts, regular shape or irregular shape of parts.
Samples:
Features:
1. PLC procedure man-machine interface operation.
2. Contact Part is customized 1.5mm Thickness SS304 weigher Scale.
3. Feeding Raw material with Sorting Device 2 Channel for feeding the product easier and fluently.
4. Control by Air Cylinder more stable.
5. Linear Filling Machine With Vibration Function Filling Hopper.
6. With Square Plastic Box Stopper Device
7. No Box No Filling.
8. Suitable for the Square Plastic Box and also the Paper Carton Box.
Work Flow:
1. Z type Elevator for the Feeding of the Raw material.
2. 10 Head 1.6L Thicker Weighing Scale for easy to set target weight.
3. Linear Filling Machine With Vibration Function Filling Hopper.
4. Suitable for the Square Plastic Box and also the Paper Carton Box.
Parameters:
| Model | LFZX-900 |
| Speed | 10-20box/min |
| Packing Size | Customizable |
| Control system | PLC |
| Power supply | 220V、50Hz |
| Dimension | 2000mm*700mm*1200mm(L*W*H) |
| Equipment material | 304 |
| Weight | 150KG |
| Description of the main packaging process | Box feeding-weighing-feeding-out of box |
Video:
