Is it possible to let machines join into the nails packing industry ? so let the workers free their hands from work and the owner could improve the daily production and save the labor cost directly. The owners pay more attention on the weight accuracy of products, because it will increase the product cost and loss some profits. It is the important key to reform a new development trend, if the machines join into productions.
The answer is absolutely.It becomes truth in the near future. Our engineers with 15 years experience in packing machines have customized the nails filling and packing machines for the owners. The nails filling & packing machines become very mature. There is just one worker to operate the machine to finish the daily production, One hour could finished 2000 cartons and each cartons weight accuracy reach ±0.3%. The machine could fill 25kgs nails into cartons and then wrap the plastic on the cartons.
Here is the machine drawing of the automatically nails filling line:
How does it work ? Please kindly check the follow pictures.
There are the cartons opening and closing machine. They are connected to the nails filling line.
There are the professional recommendations of the machines, you could learn the machine detail from them.
1.The nail filling line can achieve high productivity and greatly reduce production costs. The filling speed is 4-5 cartons/minute, 2880-3600 cartons can be filled in 12 hours, which can meet 2000 cartons/12 hours.
2.Special hardware 14-head electronic combination scale, controlled by touch screen and computer control system, high precision, measurement error of ±0.3%. Workers can set different target weights on the touch screen. The material of the combined scale is a thick stainless steel plate with a thickness of about 2.3 mm, which is resistant to heavy objects and scratches.
3.The Z-type nail elevator can automatically lift the nails from the ground to the combined scale, continuously supply the nails to the filling line, and automatically recognize the material level on the combined scale to replenish.
4.Automatic carton opening machine, which can automatically suck the carton, form, fold the bottom, and seal the carton at one time. The speed is 8-10 carton/min, the speed is adjustable, and it can realize the docking nail filling line.
5.Automatic carton sealing machine, roller conveyor design can carry heavy objects and automatically fold the lid and seal the carton, the speed is 18m/min, and the maximum carton size is (L)600X (W)500X(H)500mm.
6.Plastic wrapping machine, automatic identification of products, high-precision sealing and cutting, high-efficiency heating, speed of 6 boxes/min, maximum box size is (L) unlimited x (W) 450 x (H) 330mm
There is the pictures of 25kgs nails packed into cartons. The cartons are wrapped into plastic film.
Here are some pictures of the wholes filling line.
If you have strong interest in this 25kgs of nails filling line, feel free to contact us. Our sale manager are here to support you and recommend you suitable packing solutions. Our engineers will give you professional recommendations on the filling machines.
