Model: LD-420AH/ 520AH/ 720AH
Standard Features
1. Intelligent: Packing speed and bag length can be set through the screen without part changes;
2. Profession: Independent temperature controller with heat balance enables different packing materials;
3. Characteristic: Automatic stop function, with safe operation and saving the film;
4. Convenient: Low loss, labor saving, easy for operation and maintenance.
5. Weighing accuracy 0.4 to 1.0 gram.
E-mail: [email protected]
Tel/Whtasapp: +86 17388602385
Application:
Fasteners: screw, bolt, nut, washer, rivets, nails etc.
Plastic/Rubber Parts: wall anchor, rubber o-rings, toys, lego building bricks, small plastic parts.
Hardware Parts: hardware components, hardware connectors, metal parts etc.
Furniture Accessories: furniture connectors, furniture fasteners, furniture fittings, furniture accessories, door handle, hinge etc.
Others: small hardware or plastic parts, regular shape or irregular shape of parts.
Samples:
Features:
1. Efficient: Bag - making, filling, sealing, cutting, heating, date / lot number achieved in one time;
2. Intelligent: Packing speed and bag length can be set through the screen without part changes;
3. Profession: Independent temperature controller with heat balance enables different packing materials;
4. Characteristic: Automatic stop function, with safe operation and saving the film;
5. Convenient: Low loss, labor saving, easy for operation and maintenance.
6. Weighing accuracy 0.4 to 1.0 gram.
Parameters:
Specification (With the product size selection models) :
Type | LD-420AH | LD-520AH | LD-720AH |
Film Width | Max.420mm | Max.520mm | Max.720mm |
Bag Length | 80-300mm | 80-350mm | 100-500mm |
Bag Width | 60-200mm | 100-250mm | 180-350mm |
Film Roll Diameter | Max.320mm | Max.320mm | Max.320mm |
Packaging Rate | 5-60 bag/min | 5-60 bag/min | 5-55 Bag/min |
Power | 220V 50/60Hz 2kw | 220V 50/60Hz 3kw | 220V 50/60Hz 3kw |
Packing Film Material | OPP/CPP,OPP/P, BOPP/VMPET/PE etc | ||
Machine Size | 1217x1015x1343mm | 1488x1080x1490mm | 1780x1350x2050mm |
Machine Quality | About 650kg | About 680kg | About 750kg |
Optional Device:
1.Date coding printer, 2.Air-filling device, 3.Punching device
